MCS-MAGNUM

MCS-Magnum

Master micro controller board with twelve 0-5vdc sensor inputs, four 5vdc digital inputs, ten 230vac 6.3amp relay outputs, four 0-10vdc analog outputs, keypad, 128 x 64 dot pixel STN monochrome graphics LCD with 2.8" diagonal viewing area, real time clock, MCS-I/O, RS-232, RS-485 and Ethernet communication ports. User selectable 115vac or 230vac operation.

MCS-MAGNUM-OEM
Part Number MCS-MAGNUM-OEM
Description Magnum with OEM mounted Keypad / LCD assembly
Spec Sheets MCS-MAGNUM-OEM-Spec Sheet (PDF)PDF
MCS-MAGNUM-BACnet-PIC (PDF)PDF
Installation Magnum Getting Started Manual Rev 2.3 (PDF)PDF
MAG-KEYPAD-OEM Mounting Instructions (PDF)PDF
Wiring Diagrams MCS-MAGNUM (PDF)PDF
MCS-MAGNUM (DWG)
MAG-KEYPAD-OEM, DOOR, PANL Wiring Diagram (PDF)PDF
Dimensional Drawings MCS-MAGNUM Mounting Dimensions (PDF)PDF
MCS-MAGNUM Mounting Dimensions (DWG)
MCS-MAGNUM 3D (STP)
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
MCS-MAGNUM-PANL
Part Number MCS-MAGNUM-PANL
Description Magnum with Panel mounted Keypad / LCD assembly
Spec Sheets MCS-MAGNUM-PANL Spec Sheet (PDF)PDF
MCS-MAGNUM-BACnet-PIC (PDF)PDF
Wiring Diagrams MAG-KEYPAD-OEM, DOOR, PANL Wiring Diagram (PDF)PDF
Dimensional Drawings MCS-MAGNUM-PANEL-KEYPAD (DWG)
MCS-MAGNUM-PANEL-KEYPAD (PDF)PDF
MCS-MAGNUM 3D (STP)
Documents Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
MCS-MAGNUM-DOOR
Part Number MCS-MAGNUM-DOOR
Description Magnum with Door mounted Keypad / LCD assembly
Spec Sheets MCS-MAGNUM-DOOR Spec Sheet (PDF)PDF
MCS-MAGNUM-BACnet-PIC (PDF)PDF
Installation MAG-KEYPAD-OEM Mounting Instructions (PDF)PDF
MAG-KEYPAD-OEM, DOOR, PANL Wiring Diagram (PDF)PDF
MAG NC25 DOOR TEMPLATE-b Model (PDF)PDF
Dimensional Drawings MAG DOOR CUTOUT TEMPLATE Model (PDF)PDF
MCS-MAGNUM 3D (STP)
Documents Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
MCS-MAGNUM-N
Part Number MCS-MAGNUM-N
Description Magnum(Board only with machine mounting screws)
Spec Sheets MCS-MAGNUM-N Spec Sheet (PDF)PDF
MCS-MAGNUM-BACnet-PIC (PDF)PDF
Installation Magnum Getting Started Manual Rev 2.3 (PDF)PDF
Wiring Diagrams MCS-MAGNUM (PDF)PDF
MCS-MAGNUM (DWG)
Dimensional Drawings MCS-MAGNUM Mounting Dimensions (PDF)PDF
MCS-MAGNUM Mounting Dimensions (DWG)
MCS-MAGNUM 3D (STP)
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
Options available for the MCS-MAGNUM micro controller

Add these extensions to the end of the part number for a MCS-MAGNUM assembly listed above.

Part Number Extension Description
-24 24vac power input option

MCS-MAGNUM Control Cabinets

MCS-Magnum-SB MCS-Magnum-MB MCS-Magnum-LB
MCS-MAGNUM-SB MCS-MAGNUM-MB MCS-MAGNUM-LB

Master micro controller board with twelve 0-5vdc sensor inputs, four 5vdc digital inputs, ten 230vac 6.3amp relay outputs, four 0-10vdc analog outputs, keypad, 128 x 64 dot pixel STN monochrome graphics LCD with 2.8" diagonal viewing area, real time clock, MCS-I/O, RS-232, RS-485 and Ethernet communication ports. User selectable 115vac or 230vac operation.

MCS-MAGNUM-SB
Part Number MCS-MAGNUM-SB
Description MCS-MAGNUM in Box Enclosure 16" w x 18" h x 6" d
Spec Sheets MCS-MAGNUM-SB Spec Sheet (PDF)PDF
Wiring Diagrams Typical Power Wiring (PDF)PDF
Typical Power Wiring (DWG)DWG
Dimensional Drawings 3D-Small Box (PDF)PDF
3D-Small Box (DWG)DWG
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
MCS-MAGNUM-MB
Part Number MCS-MAGNUM-MB
Description MCS-MAGNUM in Box Enclosure 20" w x 24" h x 6" d
Spec Sheets MCS-MAGNUM-MB Spec Sheet (PDF)PDF
Wiring Diagrams Typical Power Wiring (PDF)PDF
Typical Power Wiring (DWG)DWG
Dimensional Drawings 3D-Medium Box (PDF)PDF
3D-Medium Box (DWG)DWG
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
MCS-MAGNUM-LB
Part Number MCS-MAGNUM-LB
Description MCS-MAGNUM in Box Enclosure 32" w x 27" h x 6" d
Spec Sheets MCS-MAGNUM-LB Spec Sheet (PDF)PDF
Wiring Diagrams Typical Power Wiring (PDF)PDF
Typical Power Wiring (DWG)DWG
Dimensional Drawings 3D-Large Box (PDF)PDF
3D-Large Box (DWG)DWG
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Magnum Keypad Display Manual Rev 2.0 (PDF)PDF
MCS-MAGNUM-SB-NEMA
Part Number MCS-MAGNUM-SB-NEMA
Description MCS-MAGNUM in NEMA 4 Box Enclosure 20" w x 24" h x 6" d
Spec Sheets COMING SOON
MCS-MAGNUM-MB-NEMA
Part Number MCS-MAGNUM-MB-NEMA
Description MCS-MAGNUM in NEMA 4 Box Enclosure with swing panel
24" w x 30" h x 12" d
Spec Sheets COMING SOON
MCS-MAGNUM-MLB-PC15 MCS-MAGNUM-LB-PC15
MCS-MAGNUM-MLB-PC15 MCS-MAGNUM-LB-PC15

Master micro controller board with twelve 0-5vdc sensor inputs, four 5vdc digital inputs, ten 230vac 6.3amp relay outputs, four 0-10vdc analog outputs, 10.2"wide TFT screen, 64K color, 800 × 480 pixel VGA screen resolution or 15" TFT screen, 64K color, 1024 × 768 pixel VGA screen resolution, real time clock, MCS-I/O, RS-232, RS-485 and Ethernet communication ports. User selectable 115vac or 230vac operation.

MCS-MAGNUM-MLB-PC15
Part Number MCS-MAGNUM-MLB-PC15
Description MCS-MAGNUM with 15" PC in Box Enclosure 22" w x 26" h x 7" d
Spec Sheets MCS-MAGNUM-MLB-PC15 Spec Sheet (PDF)PDF
Wiring Diagrams Medium Touch - Typical Power Wiring (PDF)PDF
Medium Touch-Typical Power Wiring (DWG)DWG
Dimensional Drawings 3D-Medium-Large Box (PDF)PDF
3D-Medium-Large Box (DWG)DWG
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Updating Touch Screen Graphics Files (PDF)PDF
MCS-MAGNUM-LB-PC15
Part Number MCS-MAGNUM-LB-PC15
Description MCS-MAGNUM with 15" PC in Box Enclosure 32" w x 27" h x 7" d
Spec Sheets MCS-MAGNUM-LB-PC15 Spec Sheet (PDF)PDF
Wiring Diagrams Medium Touch - Typical Power Wiring (PDF)PDF
Medium Touch-Typical Power Wiring (DWG)DWG
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Updating Touch Screen Graphics Files (PDF)PDF
MCS-MAGNUM-SB-PC10.2
Part Number MCS-MAGNUM-SB-PC10.2
Description MCS-MAGNUM with 10.2" PC in Box Enclosure 16" w x 18" h x 6" d
Spec Sheets COMING SOON
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Updating Touch Screen Graphics Files (PDF)PDF
MCS-MAGNUM-MB-PC10.2
Part Number MCS-MAGNUM-MB-PC10.2
Description MCS-MAGNUM with 10.2" PC in Box Enclosure 20" w x 24" h x 6" d
Spec Sheets COMING SOON
Documents Magnum Version 8 Manual Rev 3.1 (PDF)PDF
Updating Touch Screen Graphics Files (PDF)PDF
Options available for all the MCS-MAGNUM Control Cabinets listed above

All options are factory installed at MCS. When ordering, please list these as separate part numbers.

Part Number Description
-MB-MAGNUM-24 24vac power input option
-MB-24VOLT-(115/230) 115/230V to 24VCT dual pole transformer (30VA)
-MB-ALARM-(24/115/230) Red alarm indicator "ALARM"
-MB-BYPASS Momentary bypass push button "BYPASS"
-MB-COMP#(1/2/3/4) ON/OFF Compressor Run 2 position selector switch "OFF-CMP#-ON"
-MB-EMERG-SW Emergency Stop switch "EMERGENCY STOP"
-MB-RUN-LT#(1/2/3/4) Green run indicator "RUN #"
-MB-RUN-SW RUN/STOP 3 position selector switch "HAND-OFF-AUTO"
-MB-WARNING-(24/115/230) Yellow warning indicator "WARNING"
-MB-PT1000-ADAPTER Resistor adapter that converts the Hanbell motor winding temperature
-MB-CARRIER-5K-ADAPTER Resistor adapter that converts the Carrier motor winding temperature
Options available only for the MCS-MAGNUM-MB, -MB-NEMA, -MLB and
-LB Control Cabinets listed above

All options are factory installed at MCS. When ordering, please list these as separate part numbers.

Part Number Description
-MB-RO10-(24/115/230) MCS-RO10 relay output expansion board
-MB-SI16-AO4-(24/115/230) MCS-SI16-AO4 sensor input and analog output expansion board
-MB-SE-IB1 Control board for 20 ton EXV includes 115V to 24 volt transformer
-MB-SE-IB3 Control board for 30 ton EXV includes 115V to 24 volt transformer
-MB-SE-IB6 Control board for 50+ ton EXV includes 115V to 24 volt transformer

Expansion Boards

MCS-SI16-AO4

Expansion board for a MCS-MAGNUM or MCS-8 with sixteen 0-5vdc sensor inputs, four 0-10vdc analog outputs, MCS-I/O communication port, no keypad or display. Suitable replacement for MCS-SI16 board. User selectable 115vac or 230vac operation.

MCS-SI16-AO4
Part Number MCS-SI16-AO4
Description MCS-SI16-AO4 (Board only), mounts with four #6 sheet metal screws and comes with a Lexan cover
Spec Sheets MCS-SI16-AO4-Spec Sheet (PDF)PDF
Wiring Diagrams MCS-SI16-AO4 (PDF)PDF
MCS-SI16-AO4 (DWG)
Dimensional Drawings MCS-SI16-AO4 (PDF)PDF
MCS-SI16-AO4 (DWG)DWG
MCS-SI16-AO4 Mounting Dimensions (PDF)PDF
MCS-SI16-AO4 Mounting Dimensions (DWG)DWG
MCS-SI16-AO4 3D (STP)
Options available for the MCS-SI16-AO4 expansion board

Add these extensions to the end of the part number for a MCS-SI16-AO4 assembly listed above.

Part Number Extension Description
-24 24vac power input option

MCS-RO10

Expansion board for a MCS-MAGNUM or MCS-8 with ten 230vac 6.3amp relay outputs, MCS-I/O communication port, no keypad or display. Suitable replacement for MCS-RO8 board. User selectable 115vac or 230vac operation.

MCS-RO10
Part Number MCS-RO10
Description MCS-RO10 (Board only), mounts with four #6 sheet metal screws and comes with a Lexan cover
Spec Sheets MCS-RO10-Spec Sheet (PDF)PDF
Wiring Diagrams MCS-RO10 Electrical Drawing (PDF)PDF
MCS-RO10 Electrical Drawing (DWG)
Dimensional Drawings MCS-RO (PDF)PDF
MCS-RO (DWG)DWG
MCS-RO Mounting Dimensions (PDF)PDF
MCS-RO Mounting Dimensions (DWG)DWG
MCS-RO10 3D (STP)
Options available for the MCS-RO10 expansion board

Add these extensions to the end of the part number for an MCS-RO10 assembly listed above.

Part Number Extension Description
-24 24vac power input option

MCS-DS-INTERFACE

MCS-DS-INTERFACE

The MCS-DS-INTERFACE board is a substitute for the Copeland Scroll Digital™ Compressor Controller. The timing specifications are as specified by Copeland. The discharge temperature sensor can be a MCS-T100 temperature sensor or a Copeland discharge temperature sensor (Field selectable).

MCS-DS-INTERFACE
Part Number MCS-DS-INTERFACE
Description MCS_DS_INTERFACE, mounts with four #6 sheet metal screws and comes with a Lexan cover.
Spec Sheets MCS-DS-INTERFACE-Spec Sheet (PDF)PDF
Options available for the MCS-DS-INTERFACE expansion board
Part Number Description
MCS-DS-COMM
MODBUS or MCS-CONNECT communications interface board. Keyed mounting with nylon bolt to MCS-DS-INTERFACE.

MCS-MODBUS-I/O

MCS-MODBUS-I/O
MCS-MODBUS-I/O
Part Number MCS-MODBUS-I/O
Description MCS-MODBUS-I/O, mounts with four #6 sheet metal screws through nylon collars at corners of board. The MCS-MODBUS-I/O gives the MCS-MAGNUM the ability to act as a Modbus Master using the Modbus RTU Protocol. This allows the MCS-MAGNUM to communicate to Modbus slave devices (such as Variable Frequency Drives, Compressors, etc.) to send and access parameters. The MCS-MODBUS-I/O performs like an MCS-RO10 and MCS-SI16-AO4 to the MCS-MAGNUM. This allows the MCS-MAGNUM to control 10 relays, 4 analog outputs and read 16 sensors inputs. Multiple MCS-MODBUS-I/O boards may be connected to the MCS-MAGNUM following the MCS-I/O standards.
Spec Sheets MCS-MODBUS-I/O-Spec Sheet (PDF)PDF
